Reasons Your WASHER Won`t Stop Filling with Water

A washer that will not stop filling could be a huge headache. Not merely will there be the potential flooding damage but additionally the inconvenience caused as the laundry begins to accumulate. Fortunately, the most common causes of the issue are not too difficult to diagnose, and the parts responsible are easily replaced. If the cause is really a blocked pressure hose, just blowing through it can fix the issue. Continue reading to fix your overfilling washer.

Before Repairing the Washer
If the washer is full of water, run a spin cycle to empty the tub before repairing the washer. It's also advisable to disconnect the washer from the power source and turn off the hot and cold water supply lines. It is also smart to prepare a towel to wipe up any water that may spill.

Water Inlet Valve
The water inlet valve controls the flow of hot and cold water into the washer. The water inlet valve has solenoids, which open and near permit the water to flow into the washer. A washer that won't stop filling is often caused by the valve sticking and staying open.

https://appliancerepairbaltimoremd.com will find a simple test to find out if the water inlet valve reaches fault.

Turn the washer on and allow it begin to fill.
Since it is filling, disconnect the power to the washer.
If the washer will not stop filling, then your water inlet valve has failed to close, meaning it really is defective and will need to be replaced.
The water inlet valve can be examined for any obvious damage and checked for debris which may be blocking the screens inside the water inlet valve. In the event that you see any debris, removing it could solve the problem. The water inlet valve can even be tested with a multimeter on Rx1. However, you will have to check your owner`s manual for the right reading for the washer, as this may change from washer to washer.

Water Level Switch
The washer`s water level switch is really a pressure-activated switch that determines once the tub needs to stop filling with water. The switch has two sets of contacts. One contact sends capacity to the water inlet valve, which in turn causes the tub to fill. After the tub has filled, the other contact sends capacity to the motor, and the wash cycle begins. If the washer does not stop filling, it may be as the contacts have fused together.

The switch can be tested with a multimeter to determine if it is still able to carry an electric current or if it has to be replaced.

On top-loader washers, the switch is normally located behind the water level control knob in the control panel. On front-loader washers, the switch is normally located just under the most notable panel, mounted to the washer cabinet. Some top-loader washers don't have a water level switch, so check your washer`s manual to find out if your washer has one.

Assuming you have a top-loader, first remove the water level control knob.
Access the water level switch by either removing the very best panel on a front-loader washer or by unscrewing the control panel screws at the back of the control panel and then lifting it up.
Take away the pressure hose from the switch.
Remove the wiring harness and take the pull the plug on the washer.

<img width="319" src="https://irp-cdn.multiscreensite.com/cc51afc8/dms3rep/multi/tablet/Washing-Machine-Repairs1-980x390.jpg">
Attach one multimeter probe to the energy terminal and another to the water inlet valve terminal on the water level switch.
Be sure the switch has continuity, which it will.
Gently blow into the hose fitting on the switch, that ought to lead it to lose continuity. If it does not lose continuity, the contacts have fused together, and it'll should be replaced.

Water Level Switch Pressure Hose
Another common reason behind an overfilling washer may be the pressure hose attached to the water level switch. The hose connects the pressure switch to the outer tub, usually going into an air dome on the outer tub. Because the tub fills, more air pressure is created, which eventually causes the power to the water inlet valve to shut down once the tub has filled.

The reason your washer will not stop filling could be as the hose has either clogged, fallen off, or gotten a hole inside it. If you have a hole in the hose, it'll reduce the pressure and cause the water level switch not to shut off power to the water inlet valve.

Check that the hose have not fallen off and is still connected.
Disconnect the hose to check on if it is clogged.
Blow through the hose. If you have trouble blowing through the hose, chances are blocked, and you should have the ability to keep blowing through it to clear it out.
Check the air dome to ensure it is not clogged, and clear it out if it's.
Check the hose for holes. If you discover a hole, it is best to replace the hose.
Reattach the hose, making certain it is not kinked.

Water Pressure
One of the less common reasons your washer could be overfilling is that there is insufficient water pressure for the water inlet valve to work correctly. When there is insufficient water pressure, the water inlet valve will not close completely, which can cause the washer to overfill.

How much water pressure your washer requires depends on the model of the washer which you have. Therefore, you need to check your washer`s manual for the correct water pressure. If you don't have a way to check and adjust the water pressure, you need to call a plumber. However, you can check if the filters on the water inlet valve are blocked, which may be reducing the water pressure.

Main Control Board
Lastly, for those who have checked the aforementioned causes, but it is still overflowing, there may be a fault with the main control board. The control board times and initiates the cycles and monitors the functions of the washer. If the control board is faulty, it could not be communicating with the water inlet valve or the water level switch, which would cause the washer to overfill. The control board could be checked for signs of damage, like burn marks or disconnected wires. To properly check the control board, you need to call a tuned professional.
